Magnetic stirrer with heating, RCT basic (new) ANODISED 800W

Product Code: IKA20133785

Increase value Decrease value
  • Overview
  • Specifications
  • Contact us
  • Attachments
Overview
The new Benchmark for Laboratory Safety and Efficiency

The new RCT basic magnetic stirrer sets a new industry standard: currently the smallest magnetic stirrer with a heating capacity of 800 W, it combines uncompromising safety, exceptional robustness, and maximum efficiency with intuitive and easy handling.

Compact, Durable Design

  • Solid die-cast aluminum housing (IP54 protection)
  • Resistant to liquids, vapors, and mechanical impact
  • Space-saving, flexible for parallel lab setups

High quality German manufacturing

  • Fully automated production with robotic systems
  • High reliability, safety, and long service life

Enhanced Heating & Functionality

  • Scratch- and chemical-resistant anodized plate
  • Even heat distribution, fast energy transfer
  • Integrated menu with timer and wireless sensor support

Smart Timer Control

  • Programmable start options
  • Auto shut-off for heating and/or stirring
  • Acoustic end-of-process alert

High Performance & Efficiency

  • Brushless EC motor up to 1500 rpm
  • 800 W heating power, up to 9 K/min heating rate
  • Adjustable heating levels for different applications

Advanced Safety Standards

  • User-defined safety temperature
  • Medium temperature monitoring
  • Exceeds EN IEC 61010-2-010 standards
  • TÜV Süd certified (NRTL compliant)

Custom Display & Multi-Functionality

  • Configurable 14-segment display
  • Shows speed, temperature, pH, timer
  • Compatible with wireless sensors (pH measurement)

Digital Integration & Connectivity

  • RS232/USB interface with software control
  • Compatible with IKA Labworldsoft®
  • Direct communication with other IKA devices

Intelligent Safety Networking

  • Auto shut-off if stirring speed drops
  • Protects full system during 24/7 operation
  • Ideal for viscous sample processing

Future-Ready Lab Solution

  • Multi-level safety concept
  • Smart digital integration
  • Compact, efficient, and flexible design
Technical Data

Number of stirring positions  1
Stirring quantity max. per stirring position (H2O) [l]  20
Maximum load [kg]  25
Motor rating output [W]  9
Motor principle  Brushless DC
Direction of rotation  right
Speed display set-value  LED
Speed display actual-value  LED
Speed adjustment  Control knob (Rotating / Pressing)
Speed range [rpm]  50 - 1500
Setting accuracy speed [rpm]  10
Stirring bar length [mm]  20 - 80
Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h) [K]   +12
Heat output [W] 800 800
Temperature display set-value  LED
Temperature display actual-value  LED
Temperature unit  °C
Heating temperature range [°C]  Room temp. + device self heating - 310
Heat control Control knob (Rotating / Pressing)
Display resolution [K]  0.1
Temperature setting range [°C]  0 - 310
Temperature setting resolution of heating plate [K]  1
Connection for ext. temperature sensor  PT1000, ETS-D5, ETS-D7, PT wireless
Temperature setting resolution of medium [K]  1
Operating temperature min. (with external cooling) [°C]  -20
Adjustable safety circuit [°C]0 50 - 360
Set-up plate material  Aluminum with ceramic coating
Set-up plate dimensions [mm]  Ø 135
Automatic reverse rotation  optional (with IKA HUB)
Intermittent mode optional optional (with IKA HUB)
Timer  yes
Timer display  LED
Time setting min. [s]  1
Time setting max. [min] 5999
pH measurement  optional (with ETS-D7, PT wireless)
Programs  optional (with IKA HUB)
Sensor in medium detection yes
Temperature measure range PT1000 [°C]  -20 - 310
PT 1000 deviation;DIN EN 60751 Kl. A [K]  ≤ ± (0.15 +0.002xITI)
Speed deviation (no load,nominal voltage, at 1500rpm + 25 °C) [%]  ±2
Heating rate (1l H2O in H1500) [K/min]  9
Heat control accuracy of heating plate centre without vessel (at 100°C) [K]  ±5
Heat control accuracy with ext. PT1000 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) [K]  ±0.5
Heat control accuracy with ETS-D5 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) [K] ±0.5
Heat control accuracy with ETS-D7 (500ml H2O in 600ml beaker, 40mm stirring bar, 600rpm, 50°C) [K] ±0.2
Heat control accuracy with PT wireless (500ml H2O in 600ml beaker, 40mm stirring bar, 600rpm, 50°C) [K] ±0.2
Dimensions (W x H x D) [mm] 160 x 100 x 200
Weight [kg]  2.3
Permissible ambient temperature [°C]  5 - 40
Permissible relative humidity [%] 80
Protection class according to DIN EN 60529 IP 54
RS 232 interface  yes
USB interface  USB-C
WPAN interface optional  optional (USB WD)
Voltage [V]  220 - 230
Frequency [Hz]  50/60
Power input [W]  820
Power input standby [W]  0.45
